Wire Rope for Wind Power Generation

Name: Wire Rope for Wind Power Generation
Brand: Long Steel
SKU: 197343162

Wire rope for wind power: It is used for lifting equipment such as climbing free device and climbing aid used in tower barrel of wind power set

Send Inquiry

Product Introduction

The Long steel wire rope for wind power generation is a high-performance product specially designed and manufactured for the safety lifting equipment in the fan tower -- free climber, climber or hoist under the working condition. The product characteristics are mainly shown as follows:

1, High breaking force, high safety factor of equipment;

2, High fatigue life, more than 3000 times of bending fatigue under type test;

3, High corrosion resistance, can meet the neutral salt spray test (NSS) 240-720 hours without red rust;

4, Stable structure, extrusion resistance, long service life;

5, Multi-layer structure products have excellent anti-rotation performance.

4×19W-WSC 4×31WS-FC

Diameter (mm)	Reference Weight kg/100m	Min Breaking Load KN			Min Breaking Load/ kN
Diameter (mm)	Reference Weight kg/100m	1770 MPa	1960 MPa	2160 MPa	Min Breaking Load/ kN
5	10.3	15.9	17.6	19.4	20.8
6	14.8	22.9	25.4	28.0	30.0
7	20.1	31.2	34.6	38.1	40.9
8	26.2	40.8	45.2	49.8	53.4
8.3	28.8	43.9	48.6	53.6	57.4
9	33.2	51.6	57.2	63.0	67.5
9.1	34.6	52.8	58.4	64.4	69.0
10	41.0	63.7	70.6	77.8	83.4
10.2	43.5	66.3	73.4	80.9	86.7
11	49.6	77.1	85.4	94.1	101
12	59.0	91.8	102	112	120
13	69.3	108	119	131	141
14	80.4	125	138	152	163
15	92.3	143	159	175	188

Note: Cannot be used in connection with stress reliever!

5×19S-FC

5×26WS-FC

Diameter (mm)	Reference Weight kg/100m	Min Breaking Load KN			Min Breaking Load/ kN
Diameter (mm)	Reference Weight kg/100m	1770 MPa	1960 MPa	2160 MPa	Min Breaking Load/ kN
5	9.5	14.6	16.2	17.8	18.9
6	13.7	21.0	23.3	25.7	27.2
7	18.6	28.6	31.7	34.9	37.0
8	24.3	37.4	41.4	45.6	48.4
8.3	26.2	40.3	44.6	49.1	52.1
9	30.8	47.3	52.4	57.7	61.2
10	38.0	58.4	64.7	71.3	75.6
11	46.0	70.7	78.3	86.2	91.5
12	54.7	84.1	93.1	103	109
13	64.2	98.7	109	120	128
14	74.5	115	127	140	148
15	85.5	131	146	160	170

Note: Cannot be used in connection with stress reliever!

6×19W-WSC/IWRC/FC, 6×19S-WSC/IWRC/FC

Diameter (mm)	Reference Weight kg/100m		Min Breaking Load KN						Min Breaking Load/ kN
	Reference Weight kg/100m		1770 MPa		1960 MPa		2160 MPa		Min Breaking Load/ kN
	Fiber core	Steel core	Fiber core	Steel core	Fiber core	Steel core	Fiber core	Steel core	Fiber core	Steel core
5	9.5	10.5	14.60	15.8	16.2	18.4	17.8	19.2	18.1	21.6
6	13.7	15.0	21.03	22.7	23.3	26.5	25.7	27.7	26.0	31.1
7	18.6	20.5	28.62	30.9	31.7	36.0	34.9	37.7	35.5	42.3
8	24.3	26.8	37.4	40.3	41.4	47.0	45.6	49.2	46.3	55.3
8.3	26.2	28.8	40.2	43.4	44.6	50.6	49.1	53.0	49.8	59.5
9	30.8	33.9	47.3	51.0	52.4	59.5	57.7	62.3	58.6	70.0
9.5	34.3	37.8	52.7	56.8	58.4	66.3	64.3	69.4	65.3	78.0
10	38.0	41.8	58.41	63.0	64.7	73.5	71.3	76.9	72.4	86.4
11	46.0	50.6	70.68	76.2	78.3	88.9	86.2	93.0	87.6	105
12	54.7	60.2	84.11	90.7	93.1	106	103	111	104	124
13	64.2	70.6	98.71	106	109	124	120	130	122	146
14	74.5	81.9	114.5	124	127	144	140	151	142	169
15	85.5	94.1	131.4	142	146	165	160	173	163	194

Note: Cannot be used in connection with stress reliever!

5×K19S-FC

5×K26WS-FC

Diameter (mm)	Reference Weight kg/100m	Min Breaking Load KN			Min Breaking Load/ kN
Diameter (mm)	Reference Weight kg/100m	1770 MPa	1960 MPa	2160 MPa	Min Breaking Load/ kN
5	10.6	16.5	18.3	20.1	21.3
6	15.3	23.8	26.3	29.0	30.7
7	20.8	32.4	35.8	39.5	41.8
8	27.2	42.3	46.8	51.6	54.5
8.2	29.3	45.5	50.4	55.5	59.5
9	34.4	53.5	59.2	65.3	69.1
10	42.5	66.0	73.1	80.6	85.3
11	51.4	79.9	88.5	97.5	103
12	61.2	95.1	105	116	123
13	71.8	112	124	136	144
14	83.3	129	143	158	167
15	95.6	149	164	181	192

Note: Cannot be used in connection with stress reliever!

6×K19S-WSC/IWRC

Diameter (mm)	Reference Weight kg/100m	Min Breaking Load KN			Min Breaking Load/ kN
Diameter (mm)	Reference Weight kg/100m	1770 MPa	1960 MPa	2160 MPa	Min Breaking Load/ kN
5	11.6	18.4	20.3	22.4	23.0
6	16.7	26.4	29.3	32.3	33.0
7	22.8	36.0	39.9	43.9	45.0
8	29.8	47.0	52.1	57.4	58.8
9	37.7	59.5	65.9	72.6	74.4
10	46.5	73.5	81.3	89.6	91.8
11	56.3	88.9	98.4	108	111
12	67.0	106	117	129	132
13	78.6	124	137	151	155
14	91.1	144	159	176	180
15	105	165	183	202	207

Note: Cannot be used in connection with stress reliever!

product-433-346

18×7-WSC/FC

Diameter (mm)	Reference Weight kg/100m		Min Breaking Load KN						Min Breaking Load/ kN
	Reference Weight kg/100m		1770 MPa		1960 MPa		2160 MPa		Min Breaking Load/ kN
	Fiber core	Steel core	Fiber core	Steel core	Fiber core	Steel core	Fiber core	Steel core	Fiber core	Steel core
4	6.2	6.9	8.8	9.3	9.7	10.3	10.7	11.3	11.4	12.1
5	9.8	10.8	13.7	14.5	15.2	16.1	16.7	17.7	17.8	18.9
6	14.0	15.5	19.8	20.9	21.9	23.1	24.1	25.5	25.7	27.2
7	19.1	21.1	26.9	28.4	29.8	31.5	32.8	34.7	34.9	37.0
8	25.0	27.5	35.1	37.2	38.9	41.1	42.9	45.3	45.6	48.4
9	31.6	34.8	44.4	47.0	49.2	52.1	54.2	57.4	57.7	61.2
10	39.0	43.0	54.9	58.1	60.8	64.3	67.0	70.8	71.3	75.6

product-433-346

18×K7-WSC/FC

Diameter (mm)	Reference Weight kg/100m		Min Breaking Load KN						Min Breaking Load/ kN
	Reference Weight kg/100m		1770 MPa		1960 MPa		2160 MPa		Min Breaking Load/ kN
	Fiber core	Steel core	Fiber core	Steel core	Fiber core	Steel core	Fiber core	Steel core	Fiber core	Steel core
4	6.8	7.4	9.9	10.5	11.0	11.6	12.1	12.8	12.8	13.8
5	10.7	11.5	15.5	16.4	17.2	18.1	18.9	20.0	20.0	21.6
6	15.4	16.6	22.3	23.6	24.7	26.1	27.2	28.8	28.8	31.1
7	20.9	22.5	30.4	32.1	33.6	35.5	37.0	39.2	39.2	42.3
8	27.3	29.4	39.6	41.9	43.9	46.4	48.4	51.1	51.1	55.3
9	34.6	37.3	50.2	53.0	55.6	58.7	61.2	64.7	64.7	70.0
10	42.7	46.0	62.0	65.5	68.6	72.5	75.6	79.9	79.9	86.4
